US1M Surface Mount Ultrafast Rectifiers Universal Semiconductor

SMD diode US1M glass passivated chip junctions for surface mount applications, using SMA-W package. Features high efficiency, high current capability, high reliability and high surge current capability. Complies with RoHS and UL 94 V-0 flammability ratings.

Features:

Easy pick and place

Ultrafast recovery times for high efficiency

Low forward voltage, low power loss

Built-in strain relief, ideal for automated placement

High temperature soldering guaranteed: 250°C/10 seconds on terminals

Specification:

Maximum repetitive peak reverse voltage: 1000V

Maximum RMS voltage: 700V

Maximum DC blocking voltage: 1000V

Operating and storage temperature range: –55°C to +150°C

Maximum average forward rectified current at TL = 110°C: 1.0A
