MT41K128M16JT-125 2Gb x16 DDR3 SDRAM

The MT41K128M16JT is an automotive-grade 2Gb DDR3 SDRAM memory chip with 16bit data width, 17bit address bus width, and 16M words per group. FBGA Code D9PTK.

The MT41K128M16JT allows operation at a low voltage of 1.35V with an operating current of 138mA and a maximum operating voltage of 1.45V. Memory access time is 1.25ns, configured as 128MB, 16bits per space (2Gb total storage). Features include differential clock input, programmable read and write latency, refresh rates up to 64ms, automatic self-refresh, write leveling, and output driver calibration. The industrial-grade MT41K128M16JT is packaged in a 96-ball FBGA package and has an operating temperature range of -40°C to 95°C.

MT41K128M16JT-125 2Gb x16 DDR3 chip is suitable for Antminer S17 T17 S17+ T17+ S17e T17e S17 series control board.

Main features:

Data Rate: DDR3-1600

Width: x16

Operating temperature: 0°C to +95°C

Low voltage operation down to 1.35V

Backward compatible with 1.5V operation

2-Gb 16-bit DDR3 SDRAM

1.256ns access cycle

Application:

Antminer S17 series control board

Industrial Control System

External microcontroller memory

PLC
