The BAT46WH is a single planar Schottky barrier diode silkscreen marked DB with an integrated guard ring for stress protection; it is on the Whatsminer CB4-V10 control board, packaged in a small flat lead SOD123F surface mount device (SMD ) in a plastic package.

Feature:

• Low forward voltage

• Low capacitance

• Reverse voltage VR≤100 V

• AEC-Q101 qualified

• Small and flat lead SMD plastic package

Application:

• High-speed switching

• Voltage clamping

• Line termination

• Reverse polarity protection

• Whatsminer CB4-V10 control board
