The Intel Core i5-3210M is a fast dual-core processor for laptops based on the Ivy Bridge architecture. Bringing power and consistency to mobile systems, the Intel Core i5-3210M processor is designed for installation into laptop motherboards. With two cores and four threads, the 3210M has a maximum turbo clock speed of 3.1 GHz, which is effectively 64.4 or 52% slower than the current average. Thereby making better use of the CPU. Each core offers a base speed of 2.5 GHz, but can be clocked up dynamically with Turbo Boost up to 2.9 GHz (2 active cores) and 3.1 GHz (1 active core). In addition, the i5-3210M features onboard HD 4000 graphics, which is more than enough for typical desktop use, and with a TDP of just 35 watts, the i5-3210M offers reasonable but not great battery life.
Product parameters:
• Model: Intel Core i5 Mobile Processor i5-3210M
• Number of cores: 2
• Number of threads: 4
• Clock Speed: 2.5 GHz
• Maximum turbo frequency: 3.1 GHz
• Intel Smart Cache: 3 MB
• DMI: 5.0GT/s
• Lithography: 22nm
• Socket: G2 (FCBGA1023)
• Maximum thermal design power: 35 W
• Maximum memory bandwidth: 25.6 GB/s
• Graphics base frequency: 650 MHz
• Graphics maximum dynamic frequency: 1.1 GHz
• Maximum CPU configuration: 1
Installation Notes:
Step 1: Remove the screws of the cooling module and lightly pick up the cooling module;
Step 2: Screw the screw of the CPU socket 180° to the other side;
Step 3: Gently pick up the CPU vertically;
Step 4: Put the new CPU vertically into the socket, check whether the pins are all inserted after insertion, and then remember to tighten the screws;
Step 5: Apply silicone grease evenly to the lens (the less the better).
Note: Do not apply more silicone grease, or it will hinder heat dissipation.
