ADJK Synchronous Buck Converter with Internal MOSFET

MP1470 series ADJK is a high-frequency, synchronous, rectified, step-down, switch-mode converter with internal power MOSFETs. It has synchronous mode operation for higher efficiency over the output current load range. The ADJK requires a minimal number of readily available, standard, external components and is available in a space-saving 6-pin TSOT23 package.

Features:

Wide 4.7V-to-16V operating input range

Proprietary switching-loss–reduction technique, High-efficiency synchronous-mode operation

Internal AAM power-save mode for high efficiency at light load

Internal soft-start, over-current protection and hiccup, thermal shutdown

Output adjustable from 0.8V

Applications:

Game consoles

Digital set-top boxes

Flat-panel television and monitors
